Beschrijving

Exposure XM3 | Phono Versterker

De Exposure XM3 Phono versterker is een zeer muzikale MM / MC phonotrap uit de nieuwe half-brede XM3 lijn van Exposure.

Technische specificaties:

Moving Magnet Input:

• Sensitivity : 3.5mV input for 350mV output, 40dB gain setting
• Signal to Noise ratio, ref 1KHz & 350mV out :
  Gain Switch 4 ON : >70dB
  Gain Switch 4 OFF : >78dB

Moving Coil Input:

• Sensitivity : 350uV input for 350mV output, 60dB gain setting
• Signal to Noise ratio, ref 1KHz & 350mV out :
  >67db A weighted. ALL gain switches (4-6)

Algemene Specificaties:

• Frequency Response : 30Hz – 20Hz within +/- 0.25dB ref 1KHz with low frequency roll off below 30Hz
• Total Harmonic @ 1KHz, ref 350mV out <0.025% MC Input :
  Maximum Ouput Voltage : 7.8V RMS 1KHz
  Output Impedance : 50 ohms

Mains Supply : 110/120V or 220/240V @ 50/60Hz (factory set)
Power Consumption : <25W
Dimensions (WxHxD) : 218mm x 89mm x 348mm
Net Weight (unpacked) : 4kg
Gross Weight (packed) : 5kg
